NÄPFLIN TOOLS
//
www.nste.chKEGEL- UND ENTGRATSENKER
TAPER AND DEBURRING COUNTERSINKS
Art.
40.4040
40.3040
KEGEL- UND ENTGRATSENKER
TAPER AND DEBURRING COUNTERSINKS
WERKSNORM FORM ∙ WORK STANDARD TYPE C 120°
d1
Ø mm
d3
Ø mm
Gesamtlänge
Total length
L1 mm
Ø
Schaft
Shank
d2 mm
40.4040
40.3040
HSS-XE Stahl
HSS-XE Steel
€
HSS-XE Stahl + BLUE-TEC
HSS-XE Steel + BLUE-TEC
€
6,3
1,5
45,0
5,0
•
404040.0063
7,60
•
403040.0063
13,55
8,3
2,0
50,0
6,0
•
404040.0083
8,00
•
403040.0083
13,95
10,4
2,5
50,0
6,0
•
404040.0104
8,90
•
403040.0104
14,85
12,4
3,0
56,0
8,0
•
404040.0124
9,95
•
403040.0124
16,60
16,5
3,5
60,0
10,0
•
404040.0165
12,65
•
403040.0165
19,30
20,5
4,0
60,0
10,0
•
404040.0205
14,40
•
403040.0205
21,05
25,0
5,0
63,0
10,0
•
404040.0250
18,15
•
403040.0250
25,55
HSS-XE Stahl
HSS-XE Steel
HSS-XE Stahl + BLUE-TEC beschichtet
HSS-XE Steel + BLUE-TEC coated
Inhalt / Content
Ø
6,3 ∙ 8,3 ∙ 10,4 ∙ 12,4 ∙
16,5 ∙ 20,5 mm (40.4040)
Inhalt / Content
Ø
6,3 ∙ 8,3 ∙ 10,4 ∙ 12,4 ∙
16,5 ∙ 20,5 mm (40.3040)
Inhalt / Content
Ø
6,3 ∙ 10,4 ∙ 16,5 ∙
20,5 ∙ 25 mm (40.4040)
Inhalt / Content
Ø
6,3 ∙ 10,4 ∙ 16,5 ∙
20,5 ∙ 25 mm (40.3040)
SETS
d2
l1
d1 d3
120°
ART.
404090.050
ART.
403090.050
ART.
404090.060
ART.
403090.060
€
67,85
€
105,65
€
68,05
€
100,65
BEDIENUNGSHINWEISE
OPERATING INSTRUCTION
SEITE/ PAGE 42
